Description
Standard Treat Widths
Enercon’s specifically designed blown film treater is offered in 4 treat widths:
- 42″ (1000 mm)
- 52″ (1400 mm)
- 62″ (1600 mm)
- 72″ (1800 mm)
Electrode Assembly
- 1/8″ (3 mm) Stainless Steel, Flip-Type Segments, Custom Manufactured
- 1.25″ (32 mm) Electrode Width (Determines Electrode Area & Dwell Time)
- Electrode Air-Gap Adjustable from Outside the Station
- Manual Lever and Lock Mechanism for Retraction for Each Assembly
- 2-side Treatment – One Electrode Assembly Per Side
- High Voltage Transformer (XFMR) with 10′ (3 meters) of HV wire
Treater (Ground) Roll
- 3.9″ (100 mm) Diameter, Steel, Dead Shaft Mounted on Free-Running Bearings
- Silicone Sleeve Dielectric
- Frame Construction
- Aluminum End Plates
- Aluminum Extrusion Tie-Bars
- Bolted Frame
- Aluminum Ozone Exhaust Flange
Safety
- Lexan Station Covers – Provide Complete Visibility & Hinge for Easy Threading
- Magnetic Safety Switches on Hinged Station Covers
- G-10 Insulator Isolates Retraction Handle from Electrode
- Ozone Exhaust Flange on Opposite End from High Voltage Connections
- Zero Speed Sensor Shuts Down Power Supply When Line Stops
- NEMA 1 Low Voltage Terminal Box for Speed Sensor and Interlock Connections
Blown Film Options
- Pneumatically Actuated Electrode Retraction
- Electronic Air Flow Switch Mounted in Station Exhaust Duct
- Ceramic or Epoxy Covered (Ground) Treater Roll
- Bracket for Mounting High Voltage Transformer (XFMR) to Station
Blown-Film Benefits
- Compact simple construction
- Easy to thread, simple air gap adjustment
- Minimal investment
Blown-Film Considerations
- Available in limited sizes and speed requirements
- Aluminum electrodes are not as durable as stainless steel
- The roll covering requires repair or replacement although new ceramic coverings have greatly extended life expectancy.
| Blown Film Dimensions | |||
| Depth | Height | Width | |
| Station with mounted transformer |
20″ (508 mm) |
15″ (381 mm) |
43.25″ + TW (1099 mm + TW) |
| Station without mounted transformer |
20″ (508 mm) |
15″ (381 mm) |
23.5″ + TW (597 mm + TW) |
| TW = Treat Width | |||
