FIFE-500 Web Guiding System

Introducing the FIFE-500 web guide for narrow web and nonwoven applications. This cost-effective guiding system is easy to use and install, while using new technology to help you improve efficiency. At the heart of the FIFE-500 is a color touch screen that’s operator friendly, featuring icons and text in 16 languages to simplify operation and reduce the time necessary for training.

FIFE-500 leverages the latest technology to improve performance and brushless motors to reduce maintenance. Faster core processing speeds mean that the FIFE-500 can adapt quickly to changes in the web, even at high line speeds.


Key Features

  • Brushless motor for reduced maintenance and greater thrust
  • Guided Ball Nut adds reliability and long-term performance
  • Color touch screen with options for mounting vertically or horizontally
  • Multiple languages and icons for easy setup, training and operation
  • Cost-effective solution for narrow web and nonwoven applications
  • Compact design fits easily in tight spaces
  • Optional splice table and fine adjustment mounting bracket


  • Web WidthUp to 900 mm
  • Standard Roll Diameter40, 60, 80, 100 mm
  • Power Supply18 to 30 VDC
  • Temperature Range0 to 50˚ C
  • CertificationsCE, IEC61010-1/UL61010-1
  • LanguagesEnglish, German, French, Italian, Spanish,
    Simplified Chinese, Korean, Portuguese, Japanese,
    Swedish, Dutch, Turkish, Catalan, Vietnamese, Czech
  • Guide Span180, 200, 250, 300, 400, 500, 600 mm
  • Standard Roller Lengths160, 200, 250, 300, 350, 400, mm450, 500, 575, 600, 700, 800, 900 mm
  • Protection ClassIP54
Maximum Tension
  • Sizes 1-4355 N
  • Sizes 5-71000 N
